Optimize stacked baghouses nrog P191882 hloov plua plav pom cov ntsiab lus . 222 sq.ft cheeb tsam & qhib / qhib tsim kom txo siab. Thov ib daim ntawv qhia B2B!
Kev txwv cov pa huv huv hauv cov hnab ntim khoom tsim ua rau rov qab hnyav heev -siab, ua rau cov nqi zog siab. Kev hloov pauv hloov tau rau P191882Plua plav Lim Elementzoo daws cov centralized manifold bottlenecks. Siv qhov tseeb qhib/qhib 26-inch cylindrical chassis thiab 222.64 sq.ft ntawm precision-pleated xov xwm, nws accelerates particulate shedding thaum txo qis hauv aerodynamic kev sib txhuam, txhawb nqa cov chaw tswj xyuas kom ruaj khov kev sib txuas ua haujlwm tau zoo.
Qhib / Qhib Manifold Kev koom ua ke:Ua tsis muaj cov khoom hauv qab lub kaus mom, cov kev hloov pauv noPlua plav Lim Elementsyog tsim los rau pawg vertically, ua raws li ib tug nruam aerodynamic conduit rau channel huv si huab cua ncaj qha mus rau lub tso kiv cua.
222.64 Sq.Ft Pleat-Tip Stress Relief:Qhov chaw siab ntawm qhov chaw faib tawm tau txo qis txoj hauv kev tshaj tawm ntawm huab cua qias neeg, tiv thaiv abrasive particulates los ntawm lub cev scouring thiab txiav cov xov xwm pom.
Rigid Inner Dimension Geometry:Lub 8.375-nti sab hauv bore yog structurally reinforced los tiv thaiv tsis zoo lub tshuab nqus tsev implosion, ua kom txoj kev tso pa kom zoo thaum lub sij hawm hnyav pneumatic surges.
| Muaj Kev Sib Cais Cov Lus Qhia | Verified Engineering Tus Nqi |
| Crossover tom qab muag | Hloov pauv hloov tau rau P191882 |
| Nrhiav Identifier | Plua plav Lim Element |
| Sab nrauv Dimension (OD) | 12.75 nti (Approx . 323.8 hli) |
| Sab hauv Bore Clearance (ID) | 8.375 nti (Approx . 212.7 hli) |
| Full Component Span | 26.00 nti (kwv yees . 660.4 hli) |
| Upper Interface | Qhib dab tshos |
| Tsawg Interface | Qhib dab tshos |
| Profile Configuration | Cylindrical Round |
| Media Surface Capacity | Kwv yees li . 222.64 Sq.Ft |
Ua Ntawv:
Captures lightweight cellulose trimmings thiab airborne lint nyob rau hauv daim ntawv txiav aav. Qhov qhib - qauv tsim tiv thaiv cov fibers ntev los ntawm kev tsim cov aerodynamic blockages.
Fais fab nroj tsuag:
Lim abrasive, unburned carbon thiab ya tshauv ntawm conveyor hloov cov ntsiab lus, tswj kev nyab xeeb ambient huab cua zoo rau cov neeg ua haujlwm hauv lub hauv paus.
Metallurgy:
Tswj cov khoom tshwj xeeb tshaj plaws thaum lub sij hawm ore crushing thiab sintering, leveraging qhov loj 222 sq.ft cheeb tsam kom txhawb nqa kev ua haujlwm txuas ntxiv.
HONOR
ISO 14001 Daim Ntawv Pov Thawj
ISO 9001 Daim ntawv pov thawj
CE
SGS
Patent
Transparent B2B manufacturing drives Ayater cov haujlwm thoob ntiaj teb. Txhua interchangeablePlua plav Lim Elementyog auditedtawm tsam cov txheej txheem ISO nruj. Ua ntej xa tawm, peb ua qhov ntsuas qhov muag pom tseeb ntawm 8.375 "dab thiab pleat- qhov kev siv tau zoo los xyuas kom meej qhov tsis zoo ntawm cov khoom sib dhos, xa cov khoom siv hluav taws xob tiv thaiv hluav taws xob rau cov neeg saib xyuas thoob ntiaj teb.
Lub siab- lub peev xwm ntawv zeb tau tawm tsam nrog lub tswb ntsuas qhov sib txawv siab. Lawv cov cuab yeej cuab tam stacked lim featured nqaim puab bores, choking lub upward ntws ntawm huv si thiab ua rau kom lub load ntawm pa kiv cua. Los ntawm kev sib pauv rau Ayater P191882 tau tshajPlua plav Lim Element, qhov chaw ua lag luam loj ntawm qhov dav 8.375-nti qhib / qhib architecture. Qhov kev hloov kho tam sim no txo qis sab hauv huab cua tshaj tawm tsis kam, txo qis lub zog siab los ntawm 35% thiab txuag hluav taws xob ntau dhau ntawm 12 lub hlis.
Tswj Vertical Plenum Velocity (VPV) hauv Stacked Arrays
Nyob rau hauv siab - muaj peev xwm extraction baghouses, engineers feem ntau stacks cartridges (siv qhib / qhib designs) ua ob npaug rau qhov pom cheeb tsam yam tsis tau nce lub tshuab hneev taw. Txawm li cas los xij, qhov no tsim qhov kev sib tw aerodynamic zoo: Vertical Plenum Velocity (VPV).
Raws li cov huab cua huv huv los ntawm cov lim hauv qab mus rau sab saud, nws yuav tsum hla ncaj qha los ntawm lub hollow core ntawm lub lim sab saum toj. Yog hais tias lub sab hauv txoj kab uas hla yog tsis txaus, qhov no merging airstream accelerates hnyav. Qhov no ua rau muaj kev sib txhuam tsis sib haum xeeb-feem ntau hu ua "choke flow"- uas ua kom lub zog sib txawv thiab ua rau lub kiv cua kom haus hluav taws xob ntau dua. Lub calibrated 8.375-inch nyob rau hauv txoj kab uas hla ntawm no tshwj xeeb cartridge ua hauj lwm raws li ib tug optimized tso conduit. Nws zoo txo qis VPV, ua kom lub zog rov qab-mem tes propagates downward seamlessly thaum cov huab cua huv si khiav mus rau pem hauv ntej yam tsis muaj cab cab.
Ua haujlwm ntawm kev sib tshuam ntawm cov tshuab ua kua dej thiab kev tsim khoom lag luam, Ayater hais kom ua haujlwm siab heev, cov ntaub ntawv - tsav cov chaw tsim khoom. Los ntawm kev siv precision rotary pleaters thiab tshwj xeeb urethane bonding robotics, peb forge hnyav -lub luag hauj lwm huab cua sib cais qhov chaw. Peb lub hom phiaj tseem ceeb yog txhawm rau txhawm rau thib peb - tog cov khoom thaiv kev lag luam, ncaj qha muab cov nroj tsuag thoob ntiaj teb nrog cov cuab yeej pom tsis zoo uas xav tau kom muaj kev nyab xeeb, ua raws, thiab txuas ntxiv B2B ntau lawm.
| P527078 | P527079 |
| P527080 | P527081 |
| P528464 | P529552 |
| P531017 | P533788 |
| P535058 | P535114 |
| P543107 | P546761 |
| P546762 | P606090 |
| P607376 | P608654 |
| P613439 | P775220 |
| P778311 | P780135 |
Yog tias koj xav tau cov ntaub ntawv tshwj xeeb txog lwm cov qauv, thovtiv tauj pebncaj qha!
