UH-209 yog cov cuab yeej pom tseeb tshwj xeeb tsim los rau siab -siab hydraulic systems. Incorporating Stress Resistant Technology, nws muaj lub ntsiab lus lim corrugated thiab tiv thaiv - cov qauv zoo li qub kom cuam tshuam cov khoom sib kis ntawm 1μm mus rau 13μm hauv cov roj hydraulic. Nrog rau qhov ntsuas kev ua haujlwm siab ntawm 42MPa, nws yog qhov tsim nyog rau kev siv siab siv xws li siv tshuab, metallurgy, thiab cua zog. Cov khoom lag luam tus nqi tseem ceeb nyob rau hauv kev tiv thaiv cov khoom tseem ceeb xws li hydraulic twj thiab servo li qub los ntawm kev ua haujlwm ruaj khov, yog li txo qis qhov system tsis ua haujlwm thiab txuas ntxiv cov khoom siv lifespan thiab kev saib xyuas lub sijhawm.
UH-209 yog qhov ua haujlwm siab hydraulic lim feem ntau yog tsim los ntawmlim vaj tsev, UltiPleat SRT lim xov xwm, tiv thaiv - cov tub ntxhais zoo li qub, thiab siab - cov khoom sib khi. Thaum lub kaw lus hydraulic ua haujlwm, cov roj nkag mus rau hauv lub lim dej los ntawm qhov nkag, dhau los ntawm qhov siab -precision lim media los cuam tshuam cov impurities (txog li 3μm pom tseeb), thiab cov roj huv ntws tawm ntawm qhov hluav taws xob. Thaum qhov sib txawv ntawm qhov siab mus txog qhov teeb tsa tus nqi, cov khoom lim tuaj yeem hloov kho kom huv si.
| Qeb | Paub meej |
|---|---|
| Daim ntawv thov | Mobile hydraulic systems (excavators, loaders); Industrial hydraulic units; Siab -siab hydraulic circuits (txog 350 bar); Hydraulic roj ncig systems. |
| Lim Qhov Zoo | Cov av siab- tuav lub peev xwm; Anti- qauv zoo li qub (tsis txhob muaj roj oxidation); Tau tshaj cov roj hydraulic feem ntau; Lub neej ua haujlwm ntev hauv kev ua haujlwm hnyav. |
Nyob rau hauv ib txwm ua haujlwm, hydraulic roj inlet valve tseem qhib, thiab cov roj ntws mus rau hauv UH-209 lim vaj tse, dhau los ntawm UltiPleat SRT lim caij (intercepting impurities), thiab tom qab ntawd ntws tawm ntawm lub qhov hluav taws xob huv si. Thaum lub siab sib txawv ntawm lub lim dej mus txog qhov chaw pib ua ntej (qhia tias muaj kev cuam tshuam los ntawm cov kab mob sib kis), lub kaw lus ceeb toom rau kev hloov pauv hloov: kaw lub inlet valve, qhib lub valve kom tso cov roj seem, tshem tawm cov lim qub, teeb tsa UH-209 tshiab, tom qab ntawd rov qhib lub inlet valve kom rov pom dua.
|
Yam khoom |
Specification Paub meej |
|
Yam khoom qauv |
UH-209 (High-Pressure Line Lim) |
|
Rated Ua Haujlwm Siab |
42MPa (siab tshaj qhov siab: 63MPa) |
|
Kev khiav hauj lwm qhov kub thiab txias |
-30℃~ +100℃(FKM foob mus rau +120 degree) |
|
Flow Rate Range |
20L / min ~ 100L / min (nyob ntawm cov txheej txheem lim qhov tseeb) |
|
Filtration raug |
3μm, 5μm, 7μm, 10μm, 13μm (Qhov tseeb pom tseeb) |
|
Lim Element Beta Tus Nqi (ISO 16889) |
ₓ(c) Ntau dua lossis sib npaug rau 2000 (x=pom tseeb, piv txwv li, ₅(c) Ntau dua lossis sib npaug rau 2000) |
|
Kua Compatibility |
Tau tshaj cov roj ntxhia, dej-glycol, roj- dej emulsion, cov dej muaj dej ntau; FKM foob tau tshaj phosphate ester, roj hluavtaws hluavtaws |
|
Khoom siv tsev |
Carbon steel (tus qauv) / Stainless hlau (yeem, rau qhov chaw corrosive) |
|
Txoj Kev Mounting |
Hauv - kab kev teeb tsa, qhov chaw nres nkoj loj: DN19 / DN25 (xov tooj txuas) |
|
Lim Element tawg siab |
10bar (raws li ISO 2941 tus qauv) |
|
Cyclic Fatigue Lub Neej |
Ua raws li ISO 3724 tus qauv, tsis muaj kev puas tsuaj tom qab 10⁶ cycle tests |
|
Filter Element Model Piv txwv |
Lim Media |
Khoom siv foob |
Filtration raug |
Siv tau hom kua dej |
|---|---|---|---|---|
|
UA 209AP05Z |
iav fiber ntau composite media |
Nitrile Butadiene Roj Hmab (NBR) |
5μm |
Mineral roj, roj hydraulic roj |
|
UAS 209AF10Z |
iav fiber ntau composite media |
Fluorocarbon Roj Hmab (FKM) |
10μm |
Synthetic roj, siab -kub kua |
|
UA 209AN13Z |
Cellulose media |
Nitrile Butadiene Roj Hmab (NBR) |
13μm |
General industrial hydraulic roj |
Key Performance Advantages
| Technical Feature | Core Advantage | Tus neeg siv khoom tus nqi |
| Kev ntxhov siab -Resistant Filter Media |
Inorganic fiber epoxy bonding, conical pore qauv, tsis kam mus rau cyclic flow thiab paug loading cuam tshuam |
Ua kom ruaj khov pom qhov tseeb nyob rau hauv kev ua haujlwm hnyav, ua kom cov roj huv huv. |
|
Tsis Siv Neeg Lim Cartridge Tshem Tawm Mechanism |
Xaus lub hau kev koom ua ke nrog Auto- rub tabs, rub tawm lub lim cartridge thaum tshem lub tsev |
Tsis muaj phau ntawv ntxig rau hauv lub tsev yuav tsum tau ua haujlwm; hloov tau yooj yim, txo qis downtime. |
| Ntau- txheej txheej txhawb nqa | Upstream thiab downstream mesh khaubncaws sab nraud povtseg + media txhawb txheej, optimized ntws raws | Tsis tshua muaj dej tsis kam, muaj peev xwm txaus, txuas ntxiv lim cartridge kev pab cuam lub neej |
| High -Kev Ua Tau Zoo Sealing Design | O- nplhaib foob (Nitrile roj hmab / NBR lossis Fluorocarbon roj hmab / FKM yeem) | Tiv thaiv kom tsis txhob kis kab mob, ua kom pom kev ntseeg tau |
Ayater Filtration xaOEM- sib npaug UH-209 limnrog UltiPleat SRT media, kom ntseeg tau 3μm precision thiab 350-bar siab tsis kam. Peb cov khoom tiv thaiv- zoo li qub, tsis muaj qhov tsim qauv sib tw nrog cov av{12}} tuav lub peev xwm thaum txiav nqi los ntawm 30%. Txhua chav nyob dhau ISO 9001 kev sim, lav kev sib raug zoo nrog cov xov tooj ntawm tes thiab cov tshuab hydraulic. Peb muab 48-teev thoob ntiaj teb shipping thiab 12-hli warranty, nrog rau kev pab txhawb nqa. Trust Ayater rau txhim khu kev qha, nqi-zoo pom kev daws teeb meem uas ua kom koj lub tshuab ua haujlwm zoo.
